- Case
- Tripartite tonneau
- Movement
- Automatic winding, skeletonised
- Size
- 52.63 × 34.40 × 13.00 mm
Overview
Snow-set red gold with a blue flange and an onyx centre
The red gold case is snow set across the bezel and caseband, the setting continuing onto the frame of the dial-centre plate. That frame is red gold, and inside it sits an onyx panel, matte and uniformly black against the openworked movement.
A blue flange ring follows the dial aperture, the crown is white metal, the hands are gold and the strap is grey rubber.
Key details
Case materialRed gold, snow set
Dial centreOnyx
Water resistance50 m
Design and engineering
- Onyx dial centreA black stone panel set into the centre plate, giving a flat, uniform field for the hands to read against.
- Snow settingStones of differing diameters are placed to fill the surface without a repeating grid, so that no metal shows between them. It is a technique rather than a point on the coverage scale that runs from unset through one row and mid to full.
- Blue flangeA blue ring follows the dial aperture inside the bezel, the one coloured element on an otherwise gold and black watch.
- Oversize dateSemi-instantaneous, placed horizontally under 12 o’clock, driven by two skeletonised calendar discs over a white field.
- Function selectorA push-button at 4 o’clock selects winding, neutral and hand-setting with a single push; an aperture at 4 o’clock shows W, N or H. A second push-button at 10 o’clock corrects the date.
- Going train with 20° pressure angleDeveloped for the CRMA1, evening out discrepancies between wheel axles under thermal change and normal wear.
Specifications
Technical specifications
| Reference | RM 037 |
|---|---|
| Calibre | CRMA1, in-house |
| Movement | Automatic winding, skeletonised |
| Functions | Hours, minutes, oversize date, function selector, variable-geometry rotor |
| Power reserve | Around 50 hours (± 10%) |
| Movement dimensions | 28.00 × 22.90 mm, thickness 5.79 mm |
| Jewels | 25 |
| Balance | CuBe, 4 arms, 4 setting screws, moment of inertia 7.5 mg·cm², angle of lift 50° |
| Frequency | 28,800 vph (4 Hz) |
| Balance spring | AK3 |
| Shock protection | Incabloc 908.22.211.100 (transparent) |
| Escapement wheel jewels | Rubifix (transparent) |
| Baseplate and bridges | Microblasted grade 5 titanium, electroplasma treated |
| Barrel | Fast rotating, 1 revolution in 5 hours |
| Rotor | Variable geometry; ARCAP outside edge and edge ring, heavy metal weight segment, ceramic ball bearings, OneWay® winding system |
| Going train | 20° pressure angle on the teeth |
| Case | Tripartite tonneau |
| Case dimensions | 52.63 × 34.40 × 13.00 mm |
| Case material | Red gold |
| Setting | Snow setting on the bezel and caseband; set red gold dial-centre frame |
| Dial centre | Onyx |
| Flange | Blue |
| Case assembly | 20 grade 5 titanium spline screws, 316L stainless steel washers, 2 Nitrile O-ring seals |
| Water resistance | 50 m |
| Strap | Grey rubber |
