- Case
- Tripartite tonneau
- Movement
- Automatic winding, skeletonised
- Size
- 52.63 × 34.40 × 13.00 mm
Overview
Red gold with a mid-set case and an onyx dial centre
The case is red gold throughout, set in the mid tier across the bezel and down the caseband flanks, so that the setting frames the movement rather than covering the case.
The dial-centre plate is red gold, set to match around a black onyx panel. The crown and pushers are white metal and the strap is white rubber.
Key details
Case materialRed gold, mid set
Dial centreOnyx
Power reserveAround 50 hours (± 10%)
Design and engineering
- Mid settingA defined tier on Richard Mille’s coverage scale, which runs from unset through one row and mid to full and snow. Here it is applied across the bezel and the caseband flanks, in rows divided by gold rails.
- Onyx dial centreA stone panel set into the centre plate, closing the middle of the movement while the calibre remains visible around it.
- Oversize dateSemi-instantaneous, placed horizontally under 12 o’clock and driven by two skeletonised calendar discs over a white field.
- Function selectorA push-button at 4 o’clock selects winding, neutral and hand-setting with a single push, in the manner of a gearbox; an aperture alongside shows W, N or H. A second push-button at 10 o’clock corrects the date.
- Patented stem-crown assemblyThe crown is part of the case rather than the movement, so no classical crown attachment penetrates to the heart of the calibre. It is sealed with an Alcryn® O-ring and collar.
- Case productionThe empty case requires more than 255 tooling operations and over five hours of glazing and polishing at the final stage; the profile is cut on a five-axis machine, and the Richard Mille engraving on the inside curve of the caseback takes 45 minutes per case.
Specifications
Technical specifications
| Reference | RM 037 |
|---|---|
| Calibre | CRMA1, in-house |
| Movement | Automatic winding, skeletonised |
| Functions | Hours, minutes, oversize date, function selector, variable-geometry rotor |
| Power reserve | Around 50 hours (± 10%) |
| Movement dimensions | 28.00 × 22.90 mm, thickness 5.79 mm |
| Jewels | 25 |
| Balance | CuBe, 4 arms, 4 setting screws, moment of inertia 7.5 mg·cm², angle of lift 50° |
| Frequency | 28,800 vph (4 Hz) |
| Balance spring | AK3 |
| Shock protection | Incabloc 908.22.211.100 (transparent) |
| Escapement wheel jewels | Rubifix (transparent) |
| Baseplate and bridges | Microblasted grade 5 titanium, electroplasma treated |
| Barrel | Fast rotating, 1 revolution in 5 hours |
| Rotor | Variable geometry; ARCAP outside edge and edge ring, heavy metal weight segment, ceramic ball bearings, OneWay® winding system |
| Case | Tripartite tonneau |
| Case dimensions | 52.63 × 34.40 × 13.00 mm |
| Case material | Red gold |
| Setting | Mid setting on the bezel and caseband flanks; set dial-centre plate |
| Dial centre | Onyx |
| Case assembly | 20 grade 5 titanium spline screws, 316L stainless steel washers, 2 Nitrile O-ring seals |
| Water resistance | 50 m |
| Strap | White rubber |
