- Set
- Full set
- Case
- 18k red gold, tripartite construction
- Movement
- Manual winding, calibre RM 004-V2, semi-skeletonised
Set and condition
Complete set
The watch and included items are inspected by HYPA prior to sale. A written condition report is available on request.
Original presentation box
Original box included
Original papers
Original papers included
Inspected prior to sale
Reviewed for condition, completeness and functionality. Additional details and photographs are available on request.
Condition photography
Additional close-up images of specific areas are available before purchase.
Overview
Carbon nanofibre baseplate execution
Introduced in 2005, the V2 replaced the grade 5 titanium baseplate of the V1 with carbon nanofibre. The material was selected for dimensional stability: differing temperature coefficients between movement components can disturb the going train, and a thermally stable baseplate provides a consistent foundation beneath the split-seconds mechanism.
The V2 also incorporated titanium gear wheels and levers to reduce inertia, and a revised generation of split-seconds components.
Key details
Design and engineering
- Carbon nanofibre baseplateSelected for dimensional stability under temperature variation.
- Reduced hand jumpTitanium gear wheels and levers reduce inertia, substantially eliminating the initial jump of the chronograph seconds hand on starting.
- Reduced energy drawRedesigned split-seconds components reduce friction on the spindle, decreasing energy consumption by approximately 50%.
- Titanium handsSubstituted for steel following the discovery of static charge accumulation above the carbon nanofibre baseplate; the change was retrofitted to delivered watches.
- Chronograph controlsStart and stop at 8 o’clock, reset at 10 o’clock, split-seconds at 4 o’clock, with two central chronograph seconds hands and the 30-minute counter at 9.
- Function selectorCrown-centre pusher selecting winding, neutral and hand-setting, shown by the W–N–H indicator at 3 o’clock.
Specifications
Technical specifications
| Reference | RM 004-V2 |
|---|---|
| Introduced | 2005 |
| Dimensions | Approx. 48.00 × 39.00 × 15.05 mm |
| Case | 18k red gold, tripartite construction |
| Crystal | Sapphire, front and display back |
| Water resistance | 50 m |
| Movement | Manual winding, calibre RM 004-V2, semi-skeletonised |
| Baseplate | Carbon nanofibre |
| Jewels | 30–31 depending on execution |
| Functions | Hours, minutes, seconds · Split-seconds chronograph · 30-minute totaliser · Power-reserve indicator · Torque indicator · Function indicator (W–N–H) |
| Frequency | 21,600 vph (3 Hz) |
| Power reserve | circa 70 hours |
| Chronograph | Column wheel; start/stop at 8, reset at 10, split at 4 |
| Case back | Sapphire display back |
| Dial | Skeletonised |
| Strap | Black rubber |
| Set | Full set |
| Box | Original box included |
| Papers | Original papers included |
| Price | On request |
| Availability | Available on request |
