- Case
- 18k red gold, tripartite construction
- Movement
- Manual winding, calibre RM 004-V2, semi-skeletonised
Overview
Carbon nanofibre baseplate execution
Introduced in 2005, the V2 replaced the grade 5 titanium baseplate of the V1 with carbon nanofibre. The material was selected for dimensional stability: differing temperature coefficients between movement components can disturb the going train, and a thermally stable baseplate provides a consistent foundation beneath the split-seconds mechanism.
The V2 also incorporated titanium gear wheels and levers to reduce inertia, and a revised generation of split-seconds components.
Key details
Introduced2005
Key changeCarbon nanofibre baseplate, replacing titanium
Case material18k red gold
Design and engineering
- Carbon nanofibre baseplateSelected for dimensional stability under temperature variation.
- Reduced hand jumpTitanium gear wheels and levers reduce inertia, substantially eliminating the initial jump of the chronograph seconds hand on starting.
- Reduced energy drawRedesigned split-seconds components reduce friction on the spindle, decreasing energy consumption by approximately 50%.
- Titanium handsSubstituted for steel following the discovery of static charge accumulation above the carbon nanofibre baseplate; the change was retrofitted to delivered watches.
- Chronograph controlsStart and stop at 8 o’clock, reset at 10 o’clock, split-seconds at 4 o’clock, with two central chronograph seconds hands and the 30-minute counter at 9.
- Function selectorCrown-centre pusher selecting winding, neutral and hand-setting, shown by the W–N–H indicator at 3 o’clock.
The reference
Technical specifications
| Reference | RM 004-V2 |
|---|---|
| Introduced | 2005 |
| Dimensions | Approx. 48.00 × 39.00 × 15.05 mm |
| Case | 18k red gold, tripartite construction |
| Crystal | Sapphire, front and display back |
| Water resistance | 50 m |
| Movement | Manual winding, calibre RM 004-V2, semi-skeletonised |
| Baseplate | Carbon nanofibre |
| Jewels | 30–31 depending on execution |
| Functions | Hours, minutes, seconds · Split-seconds chronograph · 30-minute totaliser · Power-reserve indicator · Torque indicator · Function indicator (W–N–H) |
| Frequency | 21,600 vph (3 Hz) |
| Power reserve | circa 70 hours |
| Chronograph | Column wheel; start/stop at 8, reset at 10, split at 4 |
| Case back | Sapphire display back |
| Dial | Skeletonised |
| Strap | Black rubber |
