- Case
- Blue sapphire
- Movement
- Automatic, calibre CRMA5, skeletonised
Overview
Sapphire-cased automatic
The RM 07-02 is a separate reference from the RM 07-01, with its own calibre and case dimensions. The case is machined from sections of coloured sapphire taken from a single block. Richard Mille states that the case requires almost forty days of machining and finishing; the tonneau form is particularly difficult to produce in sapphire because of its curved lines, and the material permits no cutting error. Sapphire rates 9 on the Mohs scale of mineral hardness.
Coloured sapphire is produced by incorporating metal oxides into the crystalline structure. Inside is the CRMA5, an in-house skeletonised automatic movement displaying hours and minutes, wound by a variable-geometry rotor. On the blue and green versions the baseplate and bridges are white gold; on the pink and brown versions they are 5N red gold. The baseplate is set with hundreds of diamonds.
Key details
Design and engineering
- Sapphire caseMachined from sections of coloured sapphire cut from a single block, requiring almost forty days of machining and finishing. Sapphire scores 9 on the Mohs scale.
- Coloured sapphireMetal oxides are incorporated into the crystalline structure to produce the colour.
- Calibre CRMA5Skeletonised in-house automatic movement with hours, minutes and variable-geometry rotor.
- Gem-set baseplateThe baseplate and bridges are machined from 18k gold, microblasted and bevelled by hand, with the baseplate set with hundreds of diamonds. On the blue version the baseplate and bridges are white gold.
- Free-sprung balance with variable inertiaThe regulator index is eliminated; four small adjustable weights are located directly on the balance.
- Gear teeth profileAll going trains in the CRMA5 use a 20° pressure angle tooth profile, equalising discrepancies between wheel axles and supporting torque transmission.
- Spline screws in grade 5 titaniumUsed for both case and bridges, allowing controlled torque during assembly.
Specifications
Technical specifications
| Reference | RM 07-02 |
|---|---|
| Dimensions | 32.90 × 46.75 × 14.35 mm |
| Case | Blue sapphire |
| Case back | Open |
| Movement | Automatic, calibre CRMA5, skeletonised |
| Baseplate and bridges | 18k white gold, microblasted and hand-bevelled, diamond set |
| Jewels | 25 |
| Balance | Free-sprung with variable inertia, 4 adjustable weights |
| Winding | Variable-geometry rotor, OneWay® ceramic system with ball bearings |
| Functions | Hours, minutes · Adjustable rotor geometry |
| Frequency | 28,800 vph (4 Hz) |
| Power reserve | circa 50 hours (± 10%) |
| Gear teeth | 20° pressure angle |
| Screws | Spline screws in grade 5 titanium, case and bridges |
| Strap | Rubber with folding clasp |
Buying with HYPA
Purchase with confidence
- Manufacturer warranty confirmed from the warranty card
- Insured worldwide delivery
- Payment by bank transfer or cryptocurrency
- Registered Australian dealerHYPA International Pty Ltd · Victorian Second-Hand Dealer Licence SHD-0018017.
- Direct specialist supportSpeak with the HYPA team before, during and after the purchase.
