- Case
- Tripartite tonneau
- Movement
- Automatic winding, skeletonised
- Size
- 52.63 × 34.40 × 13.00 mm
Overview
ATZ white ceramic with red gold and a set centre plate
ATZ is Richard Mille’s designation for white ceramic, formed under high-pressure aluminium oxide injection. It gives a hard, matte white surface that holds its colour.
Here it forms the bezel and caseback, with red gold on the crown, the pushers and the inner bezel. The dial-centre plate is red gold set with diamonds around a black panel, and the strap is white rubber.
Key details
Case materialsATZ white ceramic and red gold
MovementCalibre CRMA1, skeletonised automatic winding
Power reserveAround 50 hours (± 10%)
Design and engineering
- ATZ white ceramicHard and scratch resistant, matte in finish, and distinct from the TZP designation Richard Mille uses for black and coloured ceramic.
- Set red gold centre plateDiamonds are set into the red gold frame around a black central panel.
- Oversize dateSemi-instantaneous, placed horizontally under 12 o’clock and driven by two skeletonised calendar discs over a white field.
- Function selectorA push-button at 4 o’clock selects winding, neutral and hand-setting with a single push, in the manner of a gearbox; an aperture alongside shows W, N or H. A second push-button at 10 o’clock corrects the date.
- Patented stem-crown assemblyThe crown is part of the case rather than the movement, so no classical crown attachment penetrates to the heart of the calibre. It is sealed with an Alcryn® O-ring and collar.
- Spline screws in grade 5 titaniumUsed for the bridges, case, rotor and baseplate, giving controlled torque at assembly.
Specifications
Technical specifications
| Reference | RM 037 |
|---|---|
| Calibre | CRMA1, in-house |
| Movement | Automatic winding, skeletonised |
| Functions | Hours, minutes, oversize date, function selector, variable-geometry rotor |
| Power reserve | Around 50 hours (± 10%) |
| Movement dimensions | 28.00 × 22.90 mm, thickness 5.79 mm |
| Jewels | 25 |
| Balance | CuBe, 4 arms, 4 setting screws, moment of inertia 7.5 mg·cm², angle of lift 50° |
| Frequency | 28,800 vph (4 Hz) |
| Balance spring | AK3 |
| Shock protection | Incabloc 908.22.211.100 (transparent) |
| Escapement wheel jewels | Rubifix (transparent) |
| Baseplate and bridges | Microblasted grade 5 titanium, electroplasma treated |
| Barrel | Fast rotating, 1 revolution in 5 hours |
| Rotor | Variable geometry; ARCAP outside edge and edge ring, heavy metal weight segment, ceramic ball bearings, OneWay® winding system |
| Case | Tripartite tonneau |
| Case dimensions | 52.63 × 34.40 × 13.00 mm |
| Case materials | ATZ white ceramic and red gold |
| Dial centre | Black panel in a set red gold plate |
| Case assembly | 20 grade 5 titanium spline screws, 316L stainless steel washers, 2 Nitrile O-ring seals |
| Water resistance | 50 m |
| Strap | White rubber |
