- Movement
- Automatic winding, skeletonised
- Size
- 50.00 × 42.70 × 13.95 mm
Overview
Titanium execution of the declutchable rotor automatic
The titanium RM 030, in the model’s tonneau case of 50.00 × 42.70 × 13.95 mm on a black strap. The case is tripartite, water resistant to 50 metres through two nitrile O-ring seals, and assembled with 20 grade 5 titanium spline screws and abrasion-resistant 316L stainless steel washers.
The calibre RMAR1 provides hours, minutes, seconds, date, a winding indicator and a power-reserve indicator, with the rotor declutching at 50 hours of reserve and re-engaging at 40.
Key details
Case materialTitanium
MovementCalibre RMAR1, skeletonised automatic winding
Case dimensions50.00 × 42.70 × 13.95 mm
Design and engineering
- Declutchable rotorThe mechanism combines automatic clutching and declutching of the winding system with a torque sensor, so the spring is held at an ideal tension.
- Winding indicatorAt 12 o’clock; the power-reserve scale sits at 9 o’clock and the date at 7.
- Free-sprung balance with variable inertiaGlucydur®, four arms, moment of inertia 4.8 mg·cm², lift angle 53°.
- Titalyt®-treated titanium movementWet-sandblasted grade 5 titanium with a Titalyt® treatment.
- Case machining86 preparatory operations, 49 of them striking, before cutting and milling.
Specifications
Technical specifications
| Reference | RM 030 |
|---|---|
| Calibre | RMAR1 |
| Movement | Automatic winding, skeletonised |
| Functions | Hours, minutes, seconds, date, winding indicator, power-reserve indicator, declutchable variable-geometry rotor |
| Power reserve | Circa 55 hours |
| Declutch thresholds | Disengages at 50 hours, re-engages at 40 hours |
| Frequency | 28,800 vph (4 Hz) |
| Jewels | 40 |
| Balance | Glucydur®, 4 arms, moment of inertia 4.8 mg·cm², angle of lift 53°; free-sprung with variable inertia |
| Barrels | Two |
| Baseplate, bridges and balance-cock | Grade 5 titanium, wet sandblasted, Titalyt® treated |
| Case dimensions | 50.00 × 42.70 × 13.95 mm |
| Case shape | Tonneau, tripartite |
| Case material | Titanium |
| Case construction | 20 grade 5 titanium spline screws, 316L stainless steel washers, 2 nitrile O-ring seals |
| Crown | Torque limiting, titanium |
| Crystal | Sapphire |
| Water resistance | 50 m |
| Strap | Black rubber |
